DESCRIPTION
STD/Cera: Refractory fibre made from alumina and silica.
AZS/Cerachem: Refractory fibre made from Alumina, Silica and Zironia. All above fibres are resistant to chemical attack, except for hydrofluoric and phosphoric acids and strong alkalies.
FEATURES
- Low thermal conductivity
- Excellent thermal shock resistance
- Excellent chemical stability
- High resiliency
- Good sound absorption
- Low heat storage capacity
- Excellent Thermal stability :resist devitrification at high Temperature
Technical Details
CLASSIFICATION TEMPERATURE
- STD : 1260 ° C
- AZS : 1425 ° C
- CERA : 1260 ° C
- CERACHEM : 1425 ° C
The Maximum use temperature depends on the application.
In case of doubt, refer to MMTCL Technical service for advice
APPLICATIONS
- Raw material for the manufacturing finished products such as Boards, Shapes, Paper and Yarn etc.
- Expansion joints, Patching and emergency repairs in furnaces, Boilers, Heaters etc.
- Loose insulating fill for crowns and walls of kilns and furnaces.
- Packing material for temporary repair of insulation
- Precursor for engineered fibres
AVAILABILITY & PACKAGING
- All Bulk fibres are delivered in 20 Kgs / 25 Kgs bags (or) in cartons of 16 Kgs.
Product Details
Physical Properties | STD | AZS | CERA | CERACHEM |
Classification temperature°C | 1260 | 1425 | 1260 | 1425 |
Chemical composition (%) | ||||
Al2O3 | 43-47 | 32-36 | 42-46 | 33-37 |
SiO2 | 53-57 | 44-48 | 54-58 | 48-52 |
ZrO2 | – | 16-19 | – | 13-17 |
Fe2O3 | 0.1 | 0.1 | 0.1 | 0.1 |
CaO + MgO | 0.08 | 0.08 | 0.08 | 0.08 |
Na2O + K2O | 0.40 | 0.40 | 0.40 | 0.40 |
Specific gravity | 2.65 | 2.65 | 2.65 | 2.65 |
Fibre Diameter (Microns) | 1.5-3.0 | 1.5-3.0 | 1.5-3.0 | 1.5-3.0 |
